JC LIGHT Led Leko Profile Light OEM
Voltage：AC100-240V/50-60HZ
Power consumption：300W/400W
Light source: 300w/400w LED
Color Temperature(CCT): warm white 3200k/white 5600k/RGBW optional
CRI: >90
Material: Die-cast aluminum
LED Angle: 19°optional (customized 26°/36°/50°)
Dimmer: 0-100% linear dimming
Cut mode: manual cutting
Control mode: DMX512/master slave/auto-run
Channel: 2/4/9CH
Product Size:34x27x71cm
Package Size:34x30x72cm
N.W:9.80KGS
G.W:11.0KGS
SKU：CXD300A/CXD300B/CXD400A/CXD400B
- Description
- Details
Description
Effect:
Video:
300W 400W LED Profile Spotlight with Manual Cutting and Optional RGBW
The JC LIGHT 300W/400W LED Profile Spotlight is a professional stage lighting fixture designed for theaters, churches, studios, conference halls, weddings and event productions. Available with 300W or 400W LED light sources, it offers warm white 3200K, white 5600K and RGBW options for different lighting requirements.
Featuring CRI above 90, manual cutting, 0-100% linear dimming and multiple beam angle options, this LED profile light provides flexible beam shaping and accurate stage illumination. Its die-cast aluminum housing supports professional installation and long-term event applications.
Key Features
- 300W / 400W professional LED profile spotlight
- 300W / 400W LED light source options
- 3200K warm white option
- 5600K white option
- RGBW version optional
- CRI >90
- 19° standard beam angle option
- 26° / 36° / 50° customized beam angles available
- Manual cutting system
- 0-100% linear dimming
- DMX512 professional control
- Master-slave and auto-run modes
- 2CH / 4CH / 9CH control modes
- Die-cast aluminum housing
Model Options
| SKU | CXD300A / CXD300B / CXD400A / CXD400B |
| Power Options | 300W / 400W |
| Color Options | 3200K Warm White / 5600K White / RGBW Optional |
Technical Specifications
| Product Type | LED Profile Spotlight |
| SKU | CXD300A / CXD300B / CXD400A / CXD400B |
| Voltage | AC100-240V, 50/60Hz |
| Power Consumption | 300W / 400W |
| Light Source | 300W / 400W LED |
| Color Temperature / Color Option | 3200K Warm White / 5600K White / RGBW Optional |
| CRI | >90 |
| Material | Die-Cast Aluminum |
| LED Angle | 19° Optional; 26° / 36° / 50° Customized Options |
| Dimming | 0-100% Linear Dimming |
| Cutting Mode | Manual Cutting |
| Control Mode | DMX512 / Master-Slave / Auto-Run |
| DMX Channel | 2CH / 4CH / 9CH |
| Product Size | 34 × 27 × 71 cm |
| Package Size | 34 × 30 × 72 cm |
| Net Weight | 9.80 kg |
| Gross Weight | 11.0 kg |
300W and 400W LED Options
This profile spotlight is available with 300W and 400W LED light source options, allowing users to select the configuration according to venue size and project requirements.
3200K, 5600K and RGBW Options
The fixture is available in 3200K warm white, 5600K white and RGBW configurations, providing flexibility for stage productions, studios, theaters and event lighting applications.
CRI Above 90
With a specified CRI above 90, the white-light configurations provide accurate color rendering for applications where natural-looking illumination is important.
Manual Cutting System
The built-in manual cutting function allows operators to shape the projected light according to stage areas, scenery and lighting design requirements.
Multiple Beam Angle Options
A 19° beam angle is available, with customized 26°, 36° and 50° options for different projection distances and coverage requirements.
Professional DMX512 Control
The fixture supports DMX512, master-slave and auto-run modes, with 2CH, 4CH and 9CH channel options for different control requirements.
Application Scenarios
- Theaters
- Churches
- TV and video studios
- Conference halls
- Wedding venues
- Stage performances
- Exhibitions
- Commercial events
- Professional rental projects
Why Choose JC LIGHT
- Professional LED profile spotlight manufacturer
- 300W and 400W fixture options
- Warm white, white and RGBW configurations
- Manual beam cutting solution
- Multiple beam angle options
- DMX512 professional control support
- OEM and ODM stage lighting solutions available
CXD300A / CXD300B / CXD400A / CXD400B LED Profile Spotlight FAQ
What power options are available?
The series is available with 300W and 400W LED light source options.
What color temperature options are available?
Available options include 3200K warm white, 5600K white and RGBW.
What is the CRI of this LED profile spotlight?
The specified CRI is greater than 90.
Does this profile spotlight support beam cutting?
Yes. It features a manual cutting system.
What beam angles are available?
A 19° option is available, while 26°, 36° and 50° can be customized.
Does it support DMX512 control?
Yes. It supports DMX512, master-slave and auto-run modes.
What DMX channel modes are available?
The available channel modes are 2CH, 4CH and 9CH.
Where can this LED profile spotlight be used?
It is suitable for theaters, churches, studios, conferences, weddings, stage productions and professional rental projects.
Need wholesale pricing for the JC LIGHT 300W/400W LED Profile Spotlight? Contact JC LIGHT for OEM, ODM and professional stage lighting project solutions.
