220W 54x4W RGBW LED Par Light with 4°-60° Zoom and RDM
The JC LIGHT LS544 is a professional 220W RGBW LED Par Light equipped with 54 × 4W RGBW 4-in-1 LEDs. With a specified 4°-60° zoom range, 4,500-lumen output and flexible RGBW color mixing, the fixture is designed for stage shows, concerts, theatres, weddings, clubs and professional venue lighting systems.
The LS544 combines DMX512 and RDM control, 0-100% linear dimming, signal-hold functionality and a durable die-cast aluminum alloy housing. It also provides adjustable CCT control from 2,000K to 20,000K, making it suitable for applications requiring both creative color effects and flexible white-light output.
Key Features
- 220W professional RGBW LED Par light
- 54 × 4W RGBW 4-in-1 LEDs
- 4°-60° zoom range
- 45° LED angle with 25° option
- 2,000K-20,000K CCT control
- 4,500 lm lumen output
- 480,000 cd specified intensity
- 0-100% linear dimming
- DMX512 and RDM control
- 7CH / 14CH DMX modes
- Master-slave, sound and automatic modes
- Signal-hold function
- Thick die-cast aluminum alloy housing
- Metal PG connector
- 1.5-meter copper connection cable
- Bakelite plug
- High Color Rendering Index LED beads
- Low-noise fan-assisted cooling
- IP25 protection rating
- LED lifespan of approximately 80,000-150,000 hours
Technical Specifications
| SKU | LS544 |
| Product Type | RGBW LED Par Light |
| Input Voltage | AC100-240V, 50/60Hz |
| Power Consumption | 220W |
| Light Source | 54 × 4W RGBW 4-in-1 LEDs |
| LED Lifespan | 80,000-150,000 Hours |
| CCT Control | 2,000K-20,000K |
| LED Angle | 45° Standard / 25° Optional |
| Zoom Range | 4°-60° |
| Lumen Output | 4,500 lm |
| Intensity | 480,000 cd |
| Dimmer | 0-100% Linear Dimming |
| Control Modes | DMX512 / Master-Slave / Sound / Automatic |
| RDM | Supported |
| DMX Channels | 7CH / 14CH |
| Signal Hold | Supported |
| Housing Material | Die-Cast Aluminum Alloy |
| Connector | Metal PG Connector / Bakelite Plug |
| Connection Cable | 1.5 m Copper Cable |
| Cooling | Fan-Assisted Heat Dissipation |
| IP Rating | IP25 |
| Dimensions | 28 × 21 × 30 cm |
| Weight | 3.2 kg |
54x4W RGBW 4-in-1 LED Light Source
The LS544 uses 54 × 4W RGBW 4-in-1 LEDs, combining red, green, blue and white within the fixture for flexible color mixing. The RGBW configuration supports both saturated stage colors and adjustable white-light effects for different production requirements.
4°-60° Zoom Range
A wide 4°-60° zoom range allows the LS544 to change from concentrated illumination to broad wash coverage. This makes one fixture adaptable to different stage sizes, mounting positions and lighting designs.
2,000K-20,000K CCT Control
The fixture provides a specified 2,000K-20,000K CCT control range, giving lighting programmers additional flexibility when creating warm, neutral or cooler white-light looks within a show.
4,500 Lumen Output
The LS544 is specified with a 4,500-lumen output and 480,000 cd intensity, supporting professional stage wash applications where concentrated and controllable light output is required.
0-100% Linear Dimming
A 0-100% linear dimmer provides smooth brightness adjustment for scene transitions, live performances and programmed lighting sequences.
DMX512 and RDM Control
The LS544 supports DMX512 and integrated RDM functionality with 7CH and 14CH control modes. Master-slave, sound and automatic operation are also available for different installation and show-control requirements.
Signal-Hold Function
The built-in signal-hold function allows the fixture to maintain its current operating state if the incoming control signal is interrupted, helping prevent sudden unwanted changes during operation.
Thick Die-Cast Aluminum Housing
The LS544 uses a thick die-cast aluminum alloy housing combined with a metal PG connector, bakelite plug and copper connection cable. This construction is designed for professional stage lighting and repeated installation use.
Low-Noise Cooling System
Fan-assisted heat dissipation helps manage internal operating temperature. The supplied specification describes the fan as low-noise and smooth-running, making the fixture suitable for professional environments where operating noise is a consideration.
Application Scenarios
- Concert stage wash lighting
- Theatre lighting
- Wedding and event lighting
- DJ and nightclub lighting
- Live performance stages
- Church and worship lighting
- Banquet hall lighting
- Studio and production lighting
- Entertainment venues
- Professional rental lighting systems
- Fixed stage lighting installations
Why Choose JC LIGHT
- Professional LED Par light manufacturer
- 54 × 4W RGBW 4-in-1 LED configuration
- Wide 4°-60° zoom range
- 2,000K-20,000K CCT control
- DMX512 and RDM support
- 7CH / 14CH professional control modes
- Signal-hold functionality
- Thick die-cast aluminum housing
- Suitable for distributors, rental companies and lighting contractors
- OEM and ODM stage lighting solutions available
LS544 220W 54x4W RGBW LED Par Light FAQ
What light source does the LS544 use?
The LS544 uses 54 × 4W RGBW 4-in-1 LEDs with a total fixture power consumption of 220W.
Does the LS544 have zoom?
Yes. The fixture has a specified 4°-60° zoom range, allowing adjustment between concentrated and wider wash coverage.
What CCT range does the LS544 support?
The LS544 provides a specified 2,000K-20,000K CCT control range.
What is the output of the LS544?
The fixture is specified at 4,500 lumens with an intensity of 480,000 cd.
Does the LS544 support RDM?
Yes. The LS544 supports RDM together with DMX512 for professional lighting control applications.
What DMX channel modes are available?
The fixture supports 7CH and 14CH DMX channel modes.
What happens if the DMX signal is lost?
The LS544 includes a signal-hold function that allows the fixture to maintain its current state in the absence of a control signal.
Is the LS544 waterproof?
The LS544 has an IP25 protection rating. It should not be treated as a fully waterproof outdoor stage light and should be protected from direct rain and severe weather exposure.
