Description
Effect:
380W 7 Head LED Strobe Wash Light with RGB Auxiliary Effects
The JC LIGHT FGD07B is a professional 380W 7-head LED strobe wash light designed for concerts, clubs, festivals, live stages and professional rental lighting systems. It combines 7 × 50W warm white COB LEDs with 63 × 0.3W SMD5050 RGB LEDs to create wash, flash and auxiliary lighting effects in one compact fixture.
With 32-bit linear dimming, 1-30Hz strobe, RDM support and 8CH / 32CH DMX modes, the FGD07B provides flexible control for both simple and detailed stage programming. Its metal housing, DMX input/output and power input/output connections make it suitable for professional touring and fixed installation environments.
Key Features
- 380W professional LED strobe wash light
- 7 × 50W warm white COB LEDs
- 63 × 0.3W SMD5050 RGB LEDs
- Wash, flash and auxiliary light effects
- 0-100% 32-bit linear dimming
- 1-30Hz adjustable strobe
- DMX512 control
- Auto-run mode
- Master-slave operation
- Sound control mode
- RDM function
- 8CH / 32CH DMX channel modes
- DMX512 input and output
- Power input and output
- Metal housing
- Black finish
- Operating temperature from -30°C to 50°C
- IP20 protection rating
Technical Specifications
| SKU | FGD07B |
| Product Type | 7 Head LED Strobe Wash Light |
| Input Voltage | AC100-220V, 50/60Hz |
| Power | 380W |
| Main Light Source | 7 × 50W Warm White COB LEDs |
| RGB Auxiliary Light Source | 63 × 0.3W SMD5050 RGB LEDs |
| Effects | Wash / Flash / Auxiliary Light |
| Dimming | 0-100% Linear Dimming, 32-Bit |
| Strobe Frequency | 1-30Hz |
| Working Temperature | -30°C to 50°C |
| Control Modes | DMX512 / Auto-Run / Master-Slave / Sound |
| RDM | Supported |
| DMX Channels | 8CH / 32CH |
| Signal Connection | DMX512 Input / Output |
| Power Connection | Power Input / Output |
| Housing | Metal, Black |
| IP Rating | IP20 |
| Product Size | 56 × 50 × 10 cm |
| Package Size | 56 × 56 × 17 cm |
| Net Weight | 5.89 kg |
| Gross Weight | 7.44 kg |
7x50W Warm White COB Output
The FGD07B uses 7 × 50W warm white COB LEDs as its main light source, providing strong white wash and flash output for stage and entertainment applications.
RGB Auxiliary Lighting Effects
A secondary system of 63 × 0.3W SMD5050 RGB LEDs adds colored auxiliary lighting around the main warm white output, allowing more layered and dynamic stage effects.
Wash, Flash and Auxiliary Effects
The fixture integrates wash, flash and auxiliary light functions in one unit, helping lighting designers create multiple visual effects without relying on separate fixtures for every function.
32-Bit Linear Dimming
The 0-100% 32-bit linear dimming system supports smooth intensity transitions for fades, scene changes and programmed lighting sequences.
1-30Hz Strobe Effect
The FGD07B provides an adjustable 1-30Hz strobe frequency, allowing both slower flash effects and faster high-energy sequences for concerts, clubs and live performances.
8CH and 32CH DMX Modes
Two DMX channel configurations are available: 8CH and 32CH. This gives lighting programmers the flexibility to choose between simplified operation and more detailed effect control.
DMX512 and RDM Control
The fixture supports DMX512 with RDM functionality, together with auto-run, master-slave and sound control modes for different installation and performance requirements.
DMX and Power Input / Output
Integrated DMX512 input/output and power input/output connections make the FGD07B convenient to integrate into multi-fixture professional stage lighting systems.
Wide Operating Temperature Range
The specified operating temperature range of -30°C to 50°C supports use across a variety of indoor professional entertainment environments.
Application Scenarios
- Concert stages
- Nightclubs and entertainment venues
- DJ performances
- Music festivals
- Live event stages
- Wedding and banquet stages
- Touring productions
- TV and studio entertainment sets
- Professional rental lighting systems
- Fixed indoor stage installations
Why Choose JC LIGHT
- Professional LED strobe and wash light manufacturer
- 7 × 50W warm white COB LED configuration
- 63 × 0.3W RGB auxiliary LEDs
- Wash, flash and auxiliary effects in one fixture
- 32-bit linear dimming
- 1-30Hz adjustable strobe
- RDM support
- 8CH and 32CH DMX modes
- Suitable for distributors, rental companies and lighting contractors
- OEM and ODM professional stage lighting solutions available
FGD07B 380W 7 Head LED Strobe Wash Light FAQ
What light sources does the FGD07B use?
The fixture uses 7 × 50W warm white COB LEDs together with 63 × 0.3W SMD5050 RGB LEDs.
What effects can the FGD07B create?
The FGD07B combines wash, flash and RGB auxiliary light effects in one fixture.
What is the strobe frequency?
The fixture provides an adjustable 1-30Hz strobe frequency.
Does the FGD07B support RDM?
Yes. The fixture supports RDM functionality in addition to DMX512 control.
What DMX channel modes are available?
The FGD07B supports 8CH and 32CH DMX channel modes.
Does the fixture support power and signal linking?
Yes. The supplied specification includes DMX512 input/output and power input/output connections.
Is the FGD07B waterproof?
No. The fixture has an IP20 rating and is intended for protected indoor stage and entertainment environments rather than direct exposure to rain or water.
Where can the FGD07B 7-head strobe wash light be used?
It is suitable for concerts, clubs, DJ shows, weddings, festivals, touring productions and professional rental lighting systems.
