Description
Effect:
Video:
450W 6 Head LED Strobe Wash Light with RGB Auxiliary Effects
The JC LIGHT FGD06A is a professional 450W 6 Head LED Strobe Wash Light combining 6 × 60W warm white COB LEDs with 144 × 0.3W SMD5050 RGB LEDs. It integrates wash, flash and auxiliary color effects in one fixture, making it suitable for concerts, DJ stages, clubs, live performances and professional rental applications.
The fixture features 32-bit 0-100% linear dimming, a 1-30Hz strobe frequency and RDM support. DMX512 input/output and power input/output make it convenient to integrate multiple units into professional stage lighting systems.
Key Features
- 450W professional LED strobe wash light
- 6 × 60W warm white COB LEDs
- 144 × 0.3W SMD5050 RGB LEDs
- Wash + flash + auxiliary light effects
- 32-bit 0-100% linear dimming
- 1-30Hz strobe frequency
- DMX512 control
- RDM function
- Auto-run mode
- Master-slave operation
- Sound control mode
- 8-channel DMX control
- DMX512 input and output
- Power input and output
- Metal housing with black finish
- -30°C to 50°C operating temperature
- IP20 protection rating
Technical Specifications
| SKU | FGD06A |
| Input Voltage | AC100-220V, 50/60Hz |
| Power Consumption | 450W |
| Warm White Light Source | 6 × 60W COB LEDs |
| RGB Light Source | 144 × 0.3W SMD5050 RGB LEDs |
| Main Effects | Wash + Flash + Auxiliary Light |
| Dimming | 0-100% Linear Dimming, 32-bit |
| Strobe Frequency | 1-30Hz |
| Working Temperature | -30°C to 50°C |
| Control Modes | DMX512 / Auto Run / Master-Slave / Sound |
| RDM | Supported |
| DMX Channels | 8CH |
| Signal Connection | DMX512 Input / Output |
| Power Connection | Power Input / Output |
| Housing | Metal, Black |
| IP Rating | IP20 |
| Package Size | 157 × 36 × 27 cm |
| Gross Weight | 11.6 kg |
6x60W Warm White COB Flash Output
The FGD06A uses six 60W warm white COB LEDs to generate strong white wash and flash effects. The linear multi-head layout creates a distinctive stage appearance suitable for rhythmic effects, performance highlights and high-impact show moments.
144 RGB Auxiliary LEDs
In addition to the warm white COB sources, the fixture integrates 144 × 0.3W SMD5050 RGB LEDs. These RGB LEDs provide auxiliary color effects that can be combined with the white flash output to create more layered and dynamic stage visuals.
Wash, Flash and Auxiliary Effects
The fixture combines wash, flash and RGB auxiliary lighting in one unit. This makes it possible to use the same fixture for background color, rhythmic flashes and visual accent effects within a professional stage lighting system.
32-Bit Linear Dimming
The 32-bit 0-100% linear dimming system provides precise brightness adjustment and smoother intensity transitions for programmed lighting scenes.
1-30Hz High-Speed Strobe
An adjustable 1-30Hz strobe frequency supports both slower rhythmic flashing and rapid stroboscopic effects for concerts, clubs, DJ shows and live entertainment productions.
DMX512 and RDM Control
The FGD06A supports DMX512 and RDM, together with auto-run, master-slave and sound control modes. DMX input/output and power input/output simplify installation when several fixtures are connected within one lighting system.
Application Scenarios
- Concert stage lighting
- DJ and nightclub lighting
- Music festival productions
- Live performance stages
- Wedding and event lighting
- Entertainment venues
- Stage wash and strobe effects
- Touring productions
- Professional rental lighting systems
Why Choose JC LIGHT
- Professional LED strobe and stage effect light manufacturer
- 6 × 60W warm white COB light sources
- 144 SMD5050 RGB LEDs for auxiliary effects
- Wash, flash and auxiliary effects in one fixture
- 32-bit linear dimming
- DMX512 and RDM support
- DMX and power input/output connections
- Suitable for distributors, rental companies and event contractors
- OEM and ODM stage lighting solutions available
FGD06A 450W 6 Head LED Strobe Wash Light FAQ
What light sources does the FGD06A use?
The FGD06A uses 6 × 60W warm white COB LEDs and 144 × 0.3W SMD5050 RGB LEDs.
What effects can the FGD06A produce?
The fixture combines wash, flash and RGB auxiliary light effects in one unit.
What is the strobe frequency?
The FGD06A supports an adjustable 1-30Hz strobe frequency.
Does the FGD06A support smooth dimming?
Yes. It provides 32-bit 0-100% linear dimming for precise brightness adjustment.
Does this fixture support RDM?
Yes. The FGD06A supports RDM functionality together with standard DMX512 control.
What control modes are available?
The fixture supports DMX512, auto-run, master-slave and sound control with an 8-channel DMX configuration.
Can multiple FGD06A fixtures be connected together?
Yes. The unit provides DMX512 input/output and power input/output for integration into multi-fixture stage lighting systems.
Is the FGD06A waterproof?
No. The fixture has an IP20 rating and is primarily designed for indoor or appropriately protected stage environments.
Need wholesale pricing for the JC LIGHT FGD06A 450W 6 Head LED Strobe Wash Light? Contact JC LIGHT with your required quantity and project requirements for OEM, ODM and professional stage lighting solutions.
