Description
Parameters
OPTICAL SYSTEM
Light source: original Osram 420w lamp, CCT:7200k
Optics: 200mm large diameter
COLOR SYSTEM
Color wheel: 11 colors + white+ linear CTO color temperature adjustment
GOBO SYSTEM
Gobo wheel: 11 fixed gobo, 6 effect gobo
EFFECTS
Prism: double prism, 8 prism, 24 prism,which can be overlay and rotation
Atomization: electronic 0-100% linear atomization soft light effect, Independent single-sided high transmittance atomizing lens, achieved by electric focusing, atomizing spot uniform and soft.
Dimmer: 0-100% electronic dimming
Strobe: 0-14 t/s
MOVEMENT PARAMETER
Pan& tilt: 540°Pan scaning,270°Tilt scanning;8/16-bit smooth and accurate Pan/Tilt rotation
CONTROL AND PROGRAMMING
Control: DMX512/master-slave/Auto-run/sound/Built-in RDM program
Channel: 16CH
XY Motor: three-phase motor
Display system: 20 million pixel color LCD touch screen; Touch key
POWER SUPPLY
Voltage: AC90-260V/50-60Hz
Power consumption: 680W
DIMENSION AND WEIGHT
Product Size: 45x30x70cm
N.W: 25KGS
G.W: 27KGS
Excellent color mixing effect
Video:
680W Osram Super Beam Moving Head Light with 200mm Optics and Dual Prism
The JC LIGHT Y680 is a professional 680W super beam moving head light equipped with an original Osram lamp and a 200 mm large-diameter optical system. With a 7200K color temperature, high-output beam projection and professional color, gobo and prism effects, the fixture is designed for concerts, large stages, clubs, touring productions and rental lighting applications.
The Y680 combines 11 colors plus white, linear CTO adjustment, 11 fixed gobos, 6 effect gobos and dual 8-facet and 24-facet prisms. Electronic frost, dimming and high-speed strobe functions add further creative flexibility, while three-phase motors provide smooth 540° pan and 270° tilt movement.
Key Features
- 680W professional super beam moving head light
- Original Osram lamp
- 200 mm large-diameter optical system
- 7200K color temperature
- 11 colors plus white
- Linear CTO adjustment
- 11 fixed gobos
- 6 effect gobos
- 8-facet rotating prism
- 24-facet rotating prism
- Prism rotation and overlay effects
- Electronic frost system
- 0-100% linear frost adjustment
- Electronic dimming
- 0-14 flashes per second strobe
- 540° pan movement
- 270° tilt movement
- Three-phase motor drive
- DMX512 control
- 16 DMX channels
- 20-million-pixel color LCD touch screen
- Wide AC90-260V input
Technical Specifications
| SKU | Y680 |
| Product Type | Super Beam Moving Head Light |
| Input Voltage | AC90-260V |
| Power Consumption | 680W |
| Light Source | Original Osram Lamp |
| Optical System | 200 mm Large-Diameter Optical System |
| Color Temperature | 7200K |
| Color Wheel | 11 Colors + White |
| CTO | Linear CTO Adjustment |
| Fixed Gobos | 11 |
| Effect Gobos | 6 |
| Prism System | 8-Facet + 24-Facet Dual Prism |
| Prism Effects | Rotation / Overlay |
| Frost | Electronic Frost, 0-100% Linear Adjustment |
| Dimming | Electronic Dimming |
| Strobe | 0-14 Flashes per Second |
| Pan | 540° |
| Tilt | 270° |
| Motor | Three-Phase Motor Drive |
| Control | DMX512 |
| DMX Channels | 16CH |
| Display | 20-Million-Pixel Color LCD Touch Screen |
| Product Size | 45 × 30 × 70 cm |
| Weight | 25 kg |
Original Osram Lamp with 200mm Optical System
The Y680 uses an original Osram lamp combined with a 200 mm large-diameter optical system, designed to produce a powerful concentrated beam for large venues and long-distance stage applications.
7200K High-Output Beam
A specified 7200K color temperature provides a crisp, bright beam appearance suitable for concert stages, clubs and professional show environments where strong visual impact is required.
11 Colors Plus White with Linear CTO
The color system includes 11 colors plus white, together with linear CTO adjustment. This allows lighting programmers to create vivid color effects while also adjusting the beam toward warmer tones when required.
11 Fixed Gobos and 6 Effect Gobos
The Y680 features 11 fixed gobos and 6 effect gobos, providing a wide range of beam shapes, textures and dynamic pattern effects for concerts, clubs and entertainment productions.
8-Facet and 24-Facet Dual Prism System
The fixture includes 8-facet and 24-facet prisms with rotation and overlay capability. The dual-prism system can multiply and layer beam effects to create more complex aerial patterns.
Electronic Frost with 0-100% Adjustment
An electronic frost system with 0-100% linear adjustment allows the concentrated beam to transition into a softer and more diffused output for different scene requirements.
Electronic Dimming and High-Speed Strobe
The Y680 supports electronic dimming and strobe effects from 0-14 flashes per second, giving programmers additional control over intensity and rhythmic effects during live performances.
Smooth 540° Pan and 270° Tilt
The moving head provides 540° pan and 270° tilt movement. Three-phase motors are used to deliver smooth and precise positioning for professional show programming.
16-Channel DMX512 Control
The fixture operates through DMX512 with 16 channels, allowing integration into professional lighting consoles and synchronized stage lighting systems.
Color LCD Touch Screen
A 20-million-pixel color LCD touch screen provides an intuitive interface for fixture configuration, addressing and programming adjustments.
Application Scenarios
- Concert stages
- Large live shows
- Nightclubs and entertainment venues
- Music festivals
- Touring productions
- DJ events
- Theatre productions
- Large ceremony stages
- Professional rental lighting systems
- Fixed entertainment venue installations
Why Choose JC LIGHT
- Professional beam moving head light manufacturer
- Original Osram lamp configuration
- 200 mm large-diameter optical system
- 11 colors plus white and linear CTO
- 17 total gobo effects
- 8-facet and 24-facet dual prism system
- Electronic frost and dimming
- Three-phase motor movement system
- Suitable for rental companies, distributors and lighting contractors
- OEM and ODM professional stage lighting solutions available
Y680 680W Super Beam Moving Head Light FAQ
What light source does the Y680 use?
The Y680 uses an original Osram lamp combined with a 200 mm large-diameter optical system.
What is the color temperature of the Y680?
The fixture has a specified 7200K color temperature.
How many colors does the Y680 provide?
The color wheel includes 11 colors plus white, together with linear CTO adjustment.
How many gobos are included?
The Y680 provides 11 fixed gobos and 6 effect gobos.
What prism effects does the Y680 have?
The fixture includes 8-facet and 24-facet prisms with rotation and overlay functions.
Does the Y680 have a frost effect?
Yes. It features an electronic frost system with 0-100% linear adjustment.
What pan and tilt ranges are available?
The Y680 provides 540° pan and 270° tilt movement driven by three-phase motors.
What control system does the Y680 use?
The fixture supports DMX512 with 16 control channels and includes a color LCD touch screen for local configuration.
